| Flansch 14 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|---|---|---|---|---|---|---|
|
SH2141-5541 | 0.65 | 14 | 30 | 0.3 | |
| Größe 1.1" - Flansch 28 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
SH2281-5271 | 7 | 28 | 32 | 0.7* | |
| SH2281-5231 | 7 | 28 | 32 | 0.7* | ||
| SH2285-5271 | 14.5 | 28 | 51.5 | 0.7* | ||
| SH2285-5231 | 14.5 | 28 | 51.5 | 0.7* | ||
| Größe 1.7" - Flansch 42 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-546-5342 | 19 | 42 | 32.5 | 0.42* | |
| 103-H5205-0351 | 25 | 42 | 33 | 0.7* | ||
| 103-H5205-0312 | 25 | 42 | 33 | 0.7* | ||
| 103-H5208-0483 | 42 | 42 | 39 | 0.9 | ||
| 103-H5210-4240 | 51 | 42 | 48 | 1.0 | ||
| 103-H5210-4541 | 51 | 42 | 48 | 2.0 | ||
| 103-H5212-4640 | 65 | 42 | 59.5 | 2.0 | ||
| 103-H5210-4512 | 51 | 42 | 48 | 2.0 | ||
| 103-H5212-4610 | 65 | 42 | 59.5 | 2.0 | ||
| Größe 50 mm - Flansch 50 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H6701-0140 | 38 | 50 | 39.8 | 0.7 | |
| 103-H6703-0440 | 68 | 50 | 51.3 | 1.4 | ||
| Größe 2.2" - Flansch 56 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H7121-0440 | 49 | 56 | 41.8 | 1.50* | |
| 103-H7123-5040 | 85 | 56 | 53.8 | 2.0 | ||
| 103-H7123-5010 | 85 | 56 | 53.8 | 2.0 | ||
| 103-H7123-0140 | 110 | 56 | 53.8 | 0.70* | ||
| 103-H7123-0440 | 110 | 56 | 53.8 | 1.50* | ||
| 103-H7123-0740 | 110 | 56 | 53.8 | 2.2 | ||
| 103-H7123-0710 | 110 | 56 | 53.8 | 2.2* | ||
| 103-H7123-1749 | 110 | 56 | 53.8 | 4.0 | ||
| 103-H7123-1711 | 110 | 56 | 53.8 | 4.0 | ||
| 103-H7126-0140 | 165 | 56 | 75.8 | 0.75* | ||
| 103-H7126-0710 | 165 | 56 | 75.8 | 2.2* | ||
| 103-H7126-1740 | 165 | 56 | 75.8 | 4.0 | ||
| 103-H7126-1710 | 165 | 56 | 75.8 | 4.0 | ||
| 103-H7126-6640 | 165 | 56 | 75.8 | 5.60 | ||
| 103-H7126-6610 | 165 | 56 | 75.8 | 5.60 | ||
| 103-H7128-5740 | 200 | 56 | 94,8 | 2 | ||
| 103-H7128-5710 | 200 | 56 | 94,8 | 2 | ||
| Größe 60 mm - Flansch 60 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H7822-0740 | 170 | 60 | 53.8 | 2.2 | |
| 103-H7823-0740 | 300 | 60 | 85.8 | 2.2 | ||
| 103-H7823-1740 | 300 | 60 | 85.8 | 4.0 | ||
| 103-H7826-1642 | 380 | 60 | 103.8 | 6.0 | ||
| 103-H7823-1714 | 300 | 60 | 85.8 | 4.0 | ||
| 103-H7826-1612 | 380 | 60 | 103,8 | 6.0 | ||
| SIZE 3.4 " - [] 85.5 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
SM2861-5055 | 360 | 85.5 | 66.0 | 2 | |
| SM2861-5025 | 360 | 85.5 | 66.0 | 2 | ||
| SM2861-5255 | 360 | 85.5 | 66.0 | 6.0 | ||
| SM2861-5225 | 360 | 85.5 | 66.0 | 6.0 | ||
| SM2862-5055 | 700 | 85.5 | 96.5 | 2 | ||
| SM2862-5155 | 700 | 85.5 | 96.5 | 4 | ||
| SM2862-5125 | 700 | 85.5 | 96.5 | 4 | ||
| SM2862-5255 | 700 | 85.5 | 96.5 | 6 | ||
| SM2862-5225 | 700 | 85.5 | 96.5 | 6.0 | ||
| SM2863-5155 | 920 | 85.5 | 127.0 | 4 | ||
| SM2863-5126 | 920 | 85.5 | 127.0 | 4 | ||
| SM2863-5255 | 920 | 85.5 | 127.0 | 6 | ||
| SM2863-5225 | 920 | 85.5 | 127.0 | 6.0 | ||
| Größe 3.4" - Flansch 85.8 mm Ø | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H8221-6241 | 300 | 85.8 | 62.0 | 6.0 | |
| 103-H8221-6211 | 300 | 85.8 | 62.0 | 6.0 | ||
| 103-H8222-6340 | 560 | 85.8 | 92.2 | 6.0 | ||
| 103-H8222-6310 | 560 | 85.8 | 92.2 | 6.0 | ||
| 103-H8223-6540 | 790 | 85.8 | 125.9 | 9.0 | ||
| 103-H8223-6510 | 790 | 85.8 | 125.9 | 9.0 | ||
| SIZE 4.2" - FLANGE 106.4 mm | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H89222-6341 | 1620 | 106.4 | 163.0 | 6.00 | |
| 103-H89222-6541 | 1620 | 106.4 | 163.0 | 10.00 | ||
| 103-H89223-6341 | 2460 | 106.4 | 221.0 | 6.00 | ||
| 103-H89223-6641 | 2460 | 106.4 | 221.0 | 12.00 | ||
| 103-H89223-6641.pdf | Verfügbare Modelle | Haltemoment Motor (Ncm.) | Größe Flansch (mm.) | Länge (mm.) | Strom (Amp) | |
|
103-H89223-6611 | 2460 | 106.4 | 221.0 | 12.00 | |
